Subdistributors serve to spatially separate the main system and circuit modules.
Subdistributors provide individual luminaire monitoring without additional cables and freely programmable circuits.
Available as a fire protection E30 variant as an option.
Product data
Inserts
24 pcs.
Supply power 3 h
3650 W
Number of circuits
max. 48
Supply power 8 h
3650 W
Charger
No
Input frequency
50 / 60 Hz
Modules SAM
Optional
Output voltage AC
230 V
IO modules
No
Material
Steel sheet
CCIF
Optional
Housing color
Light grey
Networkable
No
Insulation class
IP20
Outgoing SS/SD
No
Depth
450 mm
Battery compartment
No
Width
600 mm
Supply power 1 h
3650 W
Height
900 mm
Weight
kg
Customs tariff number
85371098
Max. Output voltage DC
216 V
Inserts
24 pcs.
Number of circuits
max. 48
Charger
No
Modules SAM
Optional
IO modules
No
CCIF
Optional
Networkable
No
Outgoing SS/SD
No
Battery compartment
No
Supply power 1 h
3650 W
Supply power 3 h
3650 W
Supply power 8 h
3650 W
Input frequency
50 / 60 Hz
Output voltage AC
230 V
Material
Steel sheet
Housing color
Light grey
Insulation class
IP20
Depth
450 mm
Width
600 mm
Height
900 mm
Weight
kg
Customs tariff number
85371098
Max. Output voltage DC
216 V
